Technica Engineering

The cars of tomorrow will drive themselves. Although real road tests using physical prototype vehicles offer the highest degree of realism, the large amount of resources are needed to perform large-scale and extensive testing of vehicular networks, renders their use impossible. Simulations in large-scale virtual environments are essential to validate the performance of such solutions.

ANDi (Automotive Network Diagnoser) is a testing and analysis tool which is used for Automotive software and ECUs in every development phase.

The tool is designed to simulate electronic networks, to test components and to analyse test results.

The major strength of the ANDi tool is in-depth network analysis (of the Automotive bus communication) and testing activities in Automotive networks. ANDi can be used on Windows and Linux PCs.

ANDi (Automotive Network Diagnoser) is a testing and analysis tool which is used for Automotive software and ECUs in every development phase.

The tool is designed to simulate electronic networks, to test components and to analyse test results.

The major strength of the ANDi tool is in-depth network analysis (of the Automotive bus communication) and testing activities in Automotive networks. ANDi can be used on Windows and Linux PCs.

ANDi tool is optimized to continuously meet all current requirements of automotive testing as an effective, user-friendly framework.

ANDi test environment supports testers and developers with the validation of their ECU functions through generated residual bus simulations and intelligent message generators. This is done by using different suites from ANDi. Using suites like traffic generator (generates traffic using Network Interface Card of a PC), a powerful traffic analyzer (capable of capturing and decoding automotive traffic), and a sophisticated scripting tool (through powerful and customizable RBS, test automation, and database integration), ANDi helps testing teams to validate their ECU functions throughout the test process (planning, development, realization, and reporting). ANDi is particularly flexible and user-friendly thanks to its scope of functions, its expandability, and its graphical user interface. It also comes with some extended features like integration with other tools using google remote procedure calls gRPC, import python libraries for customization, burst generator, signal graphics, etc.

• Creating test cases
• Residual Bus Simulation (RBS)
• Traffic viewer
• Improved PCAP Recorder
• Graphical Panels
• Script debugging

• Signal Graphics
• Use of multiple communication channels at highest performance
• Math Function
• PCAP Player
• File Converter

The ANDi Ethernet Test Suite (ETS) is a solution from Technica Engineering that is adapted together with OEMs. It is used to test
